Intelligent and efficient network power protection from entry level to scaleable runtime. Ideal UPS for servers, point-of-sale, routers, switches, hubs and other network devices.

• Primary Information

  Product Description:	APC Smart-UPS X 2200 Rack/Tower LCD - UPS - 1980 Watt - 2200 VA - TAA Compliant
  Device Type:	UPS - rack-mountable / external
  Rack Size:	2U
  Input Voltage:	AC 120 V
  Output Voltage:	AC 120 V
  Power Capacity:	1980 Watt / 2200 VA
  Input Connectors:	1 x power NEMA L5-30P
  Output connectors:	6 x power NEMA 5-15R ¦ 2 x power NEMA 5-20R
  Battery:	Lead acid
  Batteries Qty:	1
  Run Time (Up To):	9.8 min at full load
  Networking:	USB
  Color:	Black
  TAA Compliant:	TAA Compliant
  Dimensions (WxDxH):	17 in x 26.3 in x 3.3 in
  Environmental Standards:	ENERGY STAR
  Manufacturer Warranty:	3-year warranty
  Designed For:	P/N: AR3003, AR3003SP, AR3006, AR3006SP, AR3103, AR3103SP, AR3106, AR3106SP, AR3357X674, AR4018SP, AR4018SPX429, AR4018SPX431, AR4018SPX432, AR4024IX431, AR4024SP, AR4024SPX429, AR4024SPX431, AR4024SPX432, AR4038IX432, AR9300SP, AR9300SP-R, AR9307SP, AR9307SP-R, NBWL0356A, SMX3000LVUS, SRT1500RMXLA

• General

  Device Type:	UPS - rack-mountable / external
  Height (Rack Units):	2U
  Color:	Black

• Power Device

  UPS Technology:	Line interactive
  Input Voltage:	AC 120 V
  Input Voltage Range:	AC 70 - 153 V
  Frequency Provided:	50/60 Hz ± 3Hz
  Frequency Required:	50/60 Hz ± 3Hz
  Input Connectors:	1 x power NEMA L5-30P
  Power Output Connectors Details:	6 x power NEMA 5-15R ¦ 2 x power NEMA 5-20R
  Output Voltage:	AC 120 V 50/60 Hz
  Power Capacity:	1980 Watt / 2200 VA
  Output Waveform:	Sinewave
  Surge Suppression:	Yes

• Battery

  Quantity:	1
  Technology:	Lead acid
  Run Time (Up To):	9.8 min at full load ¦ 25.3 min at half load

• Networking

  Remote Management Interface:

  USB

• Expansion / Connectivity

  Interfaces:	1 x management (USB) - 4 pin USB Type B ¦ 1 x EPO (emergency power off)
  Expansion Slots:	1 (total) / 1 (free) x SmartSlot

• Miscellaneous

  Rack Mounting Kit:	Included
  Features:	Audible alarm, emergency power off, LCD display, Automatic Voltage Regulation (AVR), LED indicators, overload protection, cold-start function, automatic self-test, predicitive failure notification, hot-swappable batteries
  Compliant Standards:	CSA, TUV, BSMI, NOM, UL 1778, VCCI Class A ITE, EN55022 Class A, EN 50091-2, FCC Part 15 A
  TAA Compliant:	Yes

• Sustainability Information

  ENERGY STAR:

  Yes

• Manufacturer Warranty

  Service & Support:

  Limited warranty - 3 years ¦ Limited warranty - batteries - 2 years

• Environmental Parameters

  Min Operating Temperature:	32 °F
  Max Operating Temperature:	104 °F
  Humidity Range Operating:	0 - 95%
  Sound Emission:	55 dBA

• Dimensions & Weight

  Width:	17 in
  Depth:	26.3 in
  Height:	3.3 in

• Dimensions & Weight (Shipping)

  Shipping Width:	23.5 in
  Shipping Depth:	34.2 in
  Shipping Height:	9.6 in
