For such a small profile the Rx500 has plenty of power. Boasting the same toolset available throughout the range, the Rx500 is a perfect solution where space is minimal. Onboard digital control and HDMI/SDI output to external screen at 1920 x 1080. Available as SD/HD-SDI chassis or upgradeable to 3G-SDI with a simple software option.

Features:

• Modular rack mount solution for broadcast infrastructure test and measurement
• Up to 2 module bays providing 4 simultaneous SDI channels
• Video, audio, generation, monitoring 24/7
• Choose from a range of modules including physical layer measurement, eye and jitter
• Full support 3G-SDI, HD-SDI, SD-SDI and Optical support with looping I/O
• Instruments on multi-viewer at 1920 x 1080 on HDMI/SDI output
• Simultaneous analysis and monitoring of up to 4 SDI channels
• Dolby E / AES support
• Ideal for OB operations, engineering bay, broadcast manufacturing
• Assurred ROI, low weight, low power (from 16W)
• Full generator as standard 32 patterns
• Analysis includes waveform, vectorscope, data toolsets
• 16 channels embedded audio, level meters
• Ethernet upgrade, connect and download for firmware and software
• Cool operation
• 2 year warranty. UK designed and manufactured

Specifications:

Includes:
